The Center for Nanoanalysis and Electron Microscopy (CENEM) is a facility featuring cutting-edge instrumentation, techniques and expertise required for microscopic and analytical characterization of materials and devices down to the atomic scale. CENEM focuses on several complementary analysis techniques, which closely work together: Electron Microscopy, X-ray Microscopy, Cryo-TEM, Scattering Methods, Scanning Probes and Atom Probe Microscopy.

Category: Allgemein, Outreach

This month’s image shows the crystal structure of a cobalt-base superalloy at atomic resolution (image width: 12 nm) recorded using scanning transmission electron microscopy. Superalloys of this type are produced to withstand extreme environments with temperatures above 1000 °C. In the image, you ca...

Category: Allgemein, Outreach

This light microscope image shows few layers of molybdenum disulfide (MoS2), a layered crystal held together by van der Waals forces, on a thin gold film. These very thin MoS2 flakes were made by cleaving the natural layered bulk crystal, with the gold film serving as a stabilizer. The color of the ...

Category: Allgemein, Outreach

This month’s image shows a comet-like particle gracefully navigating the (nano)cosmos. The particle is the result of an annealing experiment with a gold/nickel thin film on a zinc oxide substrate. An unexpected reaction of nickel with zinc oxide produced a tail trailing a gold particle. The image w...

Category: Allgemein, Outreach

Hopefully your spring cleaning is already done! Here you can see the world’s smallest broom in action. This SEM image shows a small metal tip used for cleaning surfaces on the nanoscale - in this case graphene, the thinnest material in existence (a single atomic layer of carbon). Graphene is cleane...

Category: Allgemein, Outreach

The transition from the colder winter and spring days to the upcoming summer with higher temperatures is in full swing. While people and nature are happily anticipating the warmer days, higher temperatures can also have a detrimental impact on the environment. Especially in the smallest length scale...
